Solar Panel 485-505W PV Module
Uniform Appearance: The surface of monocrystalline silicon is relatively smooth and uniform, giving the module a neat and aesthetically pleasing appearance.
Longer Lifespan: Monocrystalline silicon modules tend to have a longer service life and better durability, ensuring long-term performance stability.
- LESTER
- CHINA
- 14 weeks
- P SILICON
- TUV CE
- 2094×1134×35mm
- 25years
- Information
▌PRODUCT DESCRIPTION
▌SPECIFICATIONS
| MECHANICAL CHARACTERSITICS | |
| Solar Cells | Mono |
| No. of Cells | 132(6×22) |
| Dimensions | 2094×1134×35mm |
| Weight | 25.5kgs |
| Front Glass | 3.2mm coated tempered glass |
| Frame | Anodized Aluminium alloy |
| Junction Box | Ip68 rated (3 by pass diodes) |
| Output Cables | 4.0mm² |
| 300mm(+）/300mm（-） | |
| Length can be customized | |
| Connectors | Mc4 compatible |
| Mechanical load test | 5400pa |
| OPERATING CHARATERISTIC | |
| Operating Module Temperature | -40℃ to 85℃ |
| Maximum System Voltage | 1500 DC(IEC) |
| Maximum Series Fuse Rating | 25A |
| Power Tolerance | 0/+5W |
▌ELECTRICAL PARAMETERS
